Details
***NOT AVAILABLE *** 1 - Used 7 Station Tablet Press MDL ZP-9 HUADA
Model: ZP-9 HUADA
Serial Number: 15340
Motor power (kW): 2.2
Volts: 220
Punch quantity (set): 9
Max. working pressure (kN): 60
Max. tablet diameter (mm): 20
Max. tablet thickness (mm): 6
Max. filling depth (mm): 15
Max. production capacity (pc/h): 14,000
Turntable working diameter (mm): 200
Turntable speed (r/min): 0-30
Diameter of middle punch (mm): 26
Height of middle punch (mm): 22
Diameter of upper and lower punch (mm): 22
Length of upper and lower punch (mm): 115
Overall dimension: 19" x 25" x 46"
Machine weight: 727 lbs
General Information: ZP-9 Fully Automatic Rotary Tablet Press Machine is a single sided tablet press which is capable of producing tablets with diameters up to 12mm. With minimal operator and maintenance training demands, the machine provides a cost effective solution to small and medium batch tablet production.
Skidding and Load out charges: There will be loading and skidding charges added to your purchase at market rates for your convenience.
Location: Carlsbad, CA
Skidding: $625
Load Out: $625
