***NOT AVAILABLE*** 1 Used FES International Spray Dryer with High-Pressure Pump and Blower Fan

Spray Dryer
Model: NC-10-8-3-1-160-B
S/N: D-15888-4099
Power: 460 V AC, 3 Phase, 60 Hz
Natural Gas: 3500cfm
Water: 50-60 Psi, 3 gpm/min
Compressed Air: 100psi, 30 scfm, clean and dry air

High-Pressure Pump
Model: HP-700-1.25-3-P-20-3K
S/N: D-16309-4099

Feed Pump
WAUKESHA Universal model 15 [ump with double "o" - ring seal and water coolantconnections for feeding product to the high pressure pump and circulating CIP solutions.
SUMITOMO .75kVa (1.0 hp) gear drive motor; Power: 460 VAC, 60Hz, 3 phase.
WEG Inverter speed control for varying flow rated to the pump.

In-line Filters
A Dual Filter-Strainer is installed immediately shead of the product feed tank to strain the fluid product to be dried. Two strainers are furnished, so that one may be cleaned while the other is operating.
This assembly is a model M-4 screen unit with 0.8 mm (.030") unless specified otherwise by the Purchaser. Each strainer has 0.19 m² (2.0 ft²) of perforated metal.
Unit is completely piped with four (4) manually-operated butterfly valves and fittings.

High Pressure Pump

  • One Model HP-700 high pressure pump with a flow rate capacity of 1350 litres per hour of liquid seaweed slurry (standard and concentrated up to 23%). Temperature to be 37F (3C). Pressure to be 3000 psi (200 bar).
  • Type 17-4 stainless steel plungers. 29 mm (1.125") diameter hardened to Rockwell 44.
  • Field replaceble seats of Rexalloy number 35.
  • Ball style Valves.
  • USDA approved plunger seals.
  • Fluid Cylinder, type 15-5 PH stainless steel hardened to Rockwell number 33.
  • 5:1 gear reduction. 100 RPM output speed at capacity.
  • 15 horsepower 460 / 3 / 60 SUMITOMO gearmotor drive system.
  • Block mounted pressure Transmitter gauge 0-5,000 psig (0-300 bar).
  • Stainless steel adjustable legs.
  • Stainless steel type 304SS shroud covers all sides and top of pump assembly.
  • Drive components are fusion powder coated epoxy finished for long maintenance-free service.
  • Plunger solenoid water service valve.
  • Inlet water filter.
  • Plexiglas view port for plunger area.
  • View port for crankcase oil.
  • View portfor gearpak oil.

Variable Speed Control

  • A variable speed drive is provided as part of the control for operation of the high-pressure pump. The high pressure pump speed is controlled by a temperature controller that controls the spray drying chamber to an exact temperature by chaging the speed of the pumo to correct variations in inlet temperature, product feed temperature and product feed solids.
  • The variable speed controller allows for minimal use of the Bypass Relief Valve thus protecting product quality by passing it through the high pressure pump only one time.
  • The use of the variable speed drive assures close moisture control in the final dried product, which usually is physically monitored.

Inlet Air Filter

  • The 3 x 3 Inlet Air Filter unit includes a galvanized steel frame that holds nine (9) prefilters and nine (9) high effeciency final filters. There is an access door on both sides of the frame for inspeting and replacing filter elements.
  • The prefilters are a disposable media which serve to remove coarse particles from the process air stream and protect the final filters from premature fouling.
  • The final filters are disposable high efficiency modules having a minimum average efficiency of 90 - 95% when tested in accordance with ASHRAE Synthetic Dust Arrestance test procedure. They are designed to remove particles down to 5u

Blower Fan
Model: Inlet Fan
Type: BC-SW
S/N: 07-229172-1-1
Size: 300
ARR: 9R
Class: 3

Operation:
Product: Seaweed
Liquid Feed: KG/HR 2326 LBS/ HR
Feed Solids: 5%
Feed Temp: 37.4F
Inlet Temp: 32F
Exhause Temp: 140F
Evaporation Capacity: 2204 lbs/hr
Powder Rate(kg/hr): 122lbs hr
Powder Moisture: 5%

Water Make Up Tank:
FES 120L Tank

General Info:
Spray drying calculations take the ambient conditions such as humidity and temperature as well as ground-level into consideration. These parameters have a huge influence on the air amount required to dry the feed into powder. The main air system consists of air filters, pre-heating systems, air heater, supply fan and from time to time dehumidification system. The main air system is constructed according to the actual requirements of the product and the ambient conditions.

Skidding and Load out charges: There will be loading and skidding charges added to your purchase at market rates for your convenience.
Location: Springville, UT

Load Out: TBD
Skidding: TBD
