***SOLD*** 1 - Used Alcohol/ Chemical Extraction System #2
General Info:
Function
Use water and alcohol to extract efficient ingredient from natural herbs, then remove and recover residual water and alcohol, preserve the solid materials.
Theory
The low temperature vacuum concentrator evaporates and condenses water or alcohol from the materials to keep the solid products.
Application
Extraction of Chinese herbal medicine, Bio-tech product, Health food, which use of water and alcohol.
Yung Sheun Machinery Co. Explosion Proof Vacuum Concentrator which includes 17' tall mezzanine.
Model: YS- EP- AR- 400
Serial Number: Y02011044
Source: AC 460 V
MOTMR: 10 HP
Capacity: 300- 400 L/ Hr
Date: May 2012
The unit is widely used for liquid evaporation and the poultice making process in the nutraceutical, pharmaceutical, chemical and food industries. When low temperatures are applied to the vacuum this causes depressurization in the vessel that holds the concentration of the heat sensitive materials. When extracted at a specific gravity of 1.4. This equipment is highly efficient and is low energy consumption. The preliminary stage of this equipment adopts high evaporation velocity and good external cycle heating and a positive pressure evaporation stage. Water content is rapidly evaporated under the vacuum effect and foam is swept along the pipe walls to prevent material lose. A liquid material cycle naturally cycles expansion kinetic energy and gravity difference. When specific gravity approach 1.2 liquid material is transferred into final evaporation stage. Poultice is made with lower jacket heating and agitation with wall scraper could effectively prevent dense extraction cooking along internal pipe walls.
Mezzanine: 9' x 9' square (6'8" from ground to floor of mezzanine)
Continous Dynamic Reflex Extraction Auger System 54' long
Screw Diameter 14" (14 opening ports down screw)
Larger grate holes in the screw to create a better diffusion boundary layer and also speeds up the lixiviate velocity which causes a better yield up to 85%
Small coefficient of 8- 10 is acceptable ( rate of solvent to material filled in) Small amounts of lixiviated solvent saves investment
Low lixiviate temperatures from 60- 100 c mtaterials and solvents are heated evenly in continous turnover to prevent heat sensitive components from getting destroyed. Many types of materials cannot be dissolved easily which makes filtering convenient for this process.
2 Large Feeder Tanks : Model YS-ST-1400
Capacity: 1916L.
1 Drier Shell Vessel
Serial Number: 207399-2
Year Built: 2007
Alcohol Recovery System/ Cooling Tower outside
Model: YS- EP- AR- 400
Serial Number: Y02011043
Source: AC 460 V
MOTMR: 3 HP
Capacity: 300- 400 L/ Hr
Date: May 2012
Skidding and Load out charges: There will be loading and skidding charges added to your purchase at market rates for your convenience.
Location: Torrance, CA
