***SOLD*** 1-AMC Cooling Tunnel and Chocolate 46’ Depositing Line
AMC has specialized in the food processing and production field for more than 10 years and has been a global supplier for multinational companies worldwide. AMC has its own specialized AMC also holds CE, TUV, ISO, and AQA Certificates and has an R&D department specifically catering to the food and processing industries.
AMC’s unique designs allow for easy cleaning & maintenance. Precise temperature zone control, various footprint dimensions, and customizable layouts make AMC’s production lines a favorable addition to any production facility.
Depositor- https://www.coolingtunnelsystem.com/products/CE-approved-chocolate-depositing-machine.html
Video of the Depositor/cooling tunnel- https://youtu.be/pKMdbYUJxiI
Stainless Steel Chocolate Chips Depositing Machine
The chocolate depositing machine is an automatic machine for chocolate forming with the function of heating, depositing, conveying, and cooling. It can not only produce pure solid chocolate chips, but also center filling chocolate, two-color chocolate, three colors chocolate, nuts mixed chocolate, and wafer chocolate depending on its setup and customization. It's the ideal solution for confectionery and food manufacturers looking to create unique and delicious chocolate treats.
Chocolate depositing: The chocolate depositing machine provides precise and accurate depositing of melted chocolate onto the cooling belt, ensuring consistency and quality every time.
High-speed production: With the ability to deposit chocolate at high speeds, you can increase production efficiency and maximize output for your chocolate chip product production.
Easy maintenance: The chocolate depositing machines are designed for ease of use and maintenance, ensuring that your production line remains operational with minimal downtime.
Versatile use: The machine can be used with a variety of chocolate types, making it suitable for different types of confectionery production.
Specifications:
Power: 0.75kw
4 piston cylinders
Capacity(kg/h):90
Distribution plate
Independent control box
Chocolate Pump(2)
Flow rate :25L/minute
Motor power: 0. 75kw
with water jacket.
speed adjustable
Dimensions:700*300*3501mn
Materials: All in SS
Chocolate Tank
Capacity: 500kg/batch
With water jacket
With agitator
Volts:208
PH:3
HZ:60
AMPS:50
Chiller/Compressor
Volts:208
PH:3
HZ:60
AMPS:60
Cooling tunnel specifications
Beltwidth: 40”
Volts:208
PH:3
HZ:60
AMPS:70
Type: Air-cooled / Water-cooled
Weight: 150Kg/Meter
Capacity: 100-2000Kg/Hr
Speed Adjustable: 1~15 M/min
Tunnel Temp: 0~10℃
Material of Frame: Stainless Steel
Material of Belt: White PU Belt (Food industry)
Application: Food Industrial Cooling
Drive Motor: SEW / CPG 1.1~5.5KW
Compressor BITZER / COPELAND: 5~25 Hp
Condenser: BITZER / COPELAND
Control Models: PLC & Touch Panel
Working Temp: -10~10 ℃
Product set up: Product: Chocolate or Color chips
Capacity: 65~9 l kg/hour
Skidding and Load out charges: There will be loading and skidding charges added to your purchase at market rates for your convenience.
